Stereo Microscope Phone-Pcb Trinocular Hdmi Camera Simul-Focal Repair-Lab 7x45x IMX307

    Stereo Microscope Phone-Pcb Trinocular Hdmi Camera Simul-Focal Repair-Lab 7x45x IMX307 Specification & Description Summary

    Stereo Microscope Phone-Pcb Trinocular Hdmi Camera Simul-Focal Repair-Lab 7x45x IMX307 Specification

    • Brand NameEakins
    • Magnification Ratio500X & Under
    • Model NumberSimul-focal Trinocular Stereo Microscope 3.5X 7X 45X 90X Continuous Zo
    • MaterialMetal

    wy-plugin-start

    Hot Commodity

    Trinocular Stereo Microscope 7X-45X Continuous Zoom Magnification+14MP HDMI USB Microscope Video Camera for Repair iPhone PCB

    $332.99

    16MP 1080P HDMI USB Camera Trinocular Stereo Continues Zoom 7-45X Microscope for Fix Repair iPhone PCB Electronic Tools

    $356.99

    Full HD 16MP 1080P HDMI USB Video Camera Trinocular Stereo Microscope 7X-45X Continuous Zoom Magnification For Repair iPhone

    $369.99

    Trinocular Stereo Microscope Continuous Zoom 7X-45X+VGA USB AV TV Digital Industrial Video Microscope Camera +144 led Light

    $276.99

    7X-45X Trinocular Zoom Stereo Microscope 144 LED Light Measurement soft 1080P VGA HDMI Camera for Phone Repairing PCB Inspection

    $369.99

    7X-45X Trinocular Illuminated Zoom Stereo Microscope with LED Light 13MP 720P VGA HDMI Camera for Phone Repairing PCB Inspection

    $279.99

    Trinocular Stereo Microscope 3.5X-90X Continuous Zoom Magnification+14MP HDMI USB Video Camera+Big stand+0.5X/2X Objective Lens

    $386.99

    Trinocular Stereo Microscope 7X-90X Continuous Zoom Magnification+16MP 1080P HDMI USB Video Camera+144 LED Light+0.5x/2.0x Lens

    $399.99

    wy-plugin-end



    After the customer feedback using the 0.5X objective lens, the light can not be satisfied, we modified the link, add 0.3X SZMCTV 1/3 Adapter, and have a working distance of 15CM, can achieve better use effect



    Feature:

    An excellent stereo inspection microscope with intensity-adjustable 144-LED ring light
    7x-45x super wide zoom magnification power
    Bright cool light 144-LED illumination system
    High resolution with great flatness and contrast, giving sharp and clear images
    Binocular head with 45 degree inclined 360 degree swiveling eye tubes
    Sharp stereo erect images with a wide field of view
    Crystal clear original true color microscope images
    Dual eye tubes with adjustable diopters
    Large working distance
    Sturdy all-metal table stand
    Accurate alignment reduces eye strain for longer periods of viewing
    Full optical glass elements
    Precise ground glass lenses
    Full metal chrome-plated mechanical components
    Adjustable interpupillary distance
    Rubber eye-guards included


    Specification:

    Head: 360 degree rotatable 45 degree inclined binocular
    Eyepieces: 30mm super widefield high-eyepoint WF10X/20MM
    Objective Zoom Range: 0.35X-9.0X, using the Barlow lenses
    Working Distance: 4" (100mm)
    Diopter Adjustment: +/- 5dp
    Interpupillary Distance: 2-3/16" - 2-15/16"(55-75mm)
    Round Plate: 3-3/4" (95mm) in diameter
    Illumination: 144-LED Ring Light
    Power Input: 110-240V, 50-60HZ, Automatic Switching




    New upgrade to HDMI VGA video microscope camera
    The color of the camera is black
    The product uses the SONY iMX307 CMOS sensor, which solves the problem of the dim display of the old camera due to insufficient light.
    Improve image quality and digital noise reduction, increase color reproduction and 1080P output, support more languages, English, Chinese, Japanese, Spain, Russian, very suitable for phone PCB SMD soldering.


    1080P  Feature:
    High Quality, High Resolution, Clear Images
    1/2.8" SONY IMX307 CMOS
    1080P 1920*1080   1024*768 @60F/S Video Camera
    HDMI VGA Video Model
    Industry Cmos Camera. It can Show the live image directly on any HDMI monitor , Projector or TV.

    Specification:
    Model: Camera with HDMI VGA two output
    Color: black
    Sensor: 1/2.8 inch SONY IMX307
    Image Resolution: 1920*1080 1024*768 (for HDMI), 1920*1080 1024*768 (for VGA)
    Video Resolution: 1920*1080 1024*768 @ 60F/S
    Basic Function:Brightness(0-100%,Adjustable), Contrast(0-100%,Adjustable), Saturation(0-100%,Adjustable), White balance(One key white balance,Manual balance)
    Image quality adjustment:Exposure(Automatic Exposure, Manual Exposure), Color temperature(Red, Blue, Green, Adjustable)
    Freeze: Support
    Mirroring: Support
    Language: English/Chinese/Japanese/Spain/Russian
    Power supply:12V 1A
    Grid line: 15 Horizontal line, 15 Vertical line, Central scale line,Custom colors,Size
    Appearance size:50*50*58mm

    (The camera is available in black and blue, and if no information is given to us, we ship it randomly.)

    144 bright white LED bulbs
    100,000 hours of life
    Intense and focused shadow-free illumination
    The brightness of 0-100%Adjustable,high brightness
    Variable intensity control
    Power input: 100-240V, 50-60HZ
    Suit for the dia of the lens: 30mm-63mm



    A Package Including:

    1 x Trinocular Stereo Zoom Head
    1 x Pair of Super Widefield 10X20MM Eyepieces
    1 x 144-LED Ring Light
    1 x Pillar Table Stand
    1 x Focusing Rack
    1 x C-mount Adapter
    1 x Pair of Eye-Guards
    1 x Dust Cover
    1 x HDMI VGA Microscope Camera (Blue, black, random shipping)
    1 x Power supply(EU/AU)
    1 x SZMCTV 1/2 Lens
    1 x 1.0X Microscope Auxiliary Objective Lens(Protection function)
    1 x 0.5X Microscope Auxiliary Objective Lens(Working Distance 165 mm)


    B Package Including:

    1 x Trinocular Stereo Zoom Head
    1 x Pair of Super Widefield 10X20MM Eyepieces
    1 x 144-LED Ring Light
    1 x Pillar Table Stand
    1 x Focusing Rack
    1 x C-mount Adapter
    1 x Pair of Eye-Guards
    1 x Dust Cover
    1 x HDMI VGA Microscope Camera (Blue, black, random shipping)
    1 x Power supply(EU/AU)
    1 x 0.5X Adapter Lens
    1 x 1.0X Microscope Auxiliary Objective Lens(Protection function)
    1 x 0.5X Microscope Auxiliary Objective Lens(Working Distance 165 mm)
    1 x 2.0X Microscope Auxiliary Objective Lens(Working Distance 40 mm)


    C Package Including:

    1 x Trinocular Stereo Zoom Head
    1 x Pair of Super Widefield 10X20MM Eyepieces
    1 x 144-LED Ring Light
    1 x Pillar Table Stand
    1 x Focusing Rack
    1 x C-mount Adapter
    1 x Pair of Eye-Guards
    1 x Dust Cover
    1 x HDMI VGA Microscope Camera (Blue, black, random shipping)
    1 x Power supply(EU/AU)
    1 x 0.5X Adapter Lens
    1 x 1.0X Microscope Auxiliary Objective Lens(Protection function)
    1 x 0.5X Microscope Auxiliary Objective Lens(Working Distance 165 mm)
    1 x 2.0X Microscope Auxiliary Objective Lens(Working Distance 40 mm)
    1 x  Adjustable Metal Arm


    D Package Including:

    1 x Trinocular Stereo Zoom Head
    1 x Pair of Super Widefield 10X20MM Eyepieces
    1 x 144-LED Ring Light
    1 x Pillar Table Stand
    1 x Focusing Rack
    1 x C-mount Adapter
    1 x Pair of Eye-Guards
    1 x Dust Cover
    1 x HDMI VGA Microscope Camera (Blue, black, random shipping)
    1 x Power supply(EU/AU)
    1 x 0.5X Adapter Lens
    1 x 1.0X Microscope Auxiliary Objective Lens(Protection function)
    1 x 0.5X Microscope Auxiliary Objective Lens(Working Distance 165 mm)
    1 x 2.0X Microscope Auxiliary Objective Lens(Working Distance 40 mm)
    1 x  Adjustable Metal Arm
